Datascope Accutorr Plus - NIBP Pump Connector, J-505; LED Backlight Connector, J-651; Communication Connector, J-603; LCD Connector, J-8

Interconnect Cables Run List Repair Information
3 - 20 0070-10-0691 Accutorr Plus Service Manual
3.7.1.8 NIBP Pump Connector, J-505
LED
3.7.1.9 LED Backlight Connector, J-651
3.7.1.10 Communication Connector, J-603
3.7.1.11 LCD Connector, J-8
PIN # INPUT/OUTPUT DESCRIPTION NAME
1 Output pump supply +12VF
2 Input pump return PUMP*
3 Input power ground P(power ground)
PIN # INPUT/OUTPUT DESCRIPTION NAME
1 Output Min 3.4V - Max 3.6V BL+
2 Input Return BL-
PIN # INPUT/OUTPUT DESCRIPTION NAME
1 N/C N/C N/C
2 Input RS-232 RTS
3 Output RS-232 CTS
4 Output Ground DGND
5 N/C N/C N/C
6 Output Ground DGND
7 Output RS-232, Transmit EXT_TXD
8 Input RS-232, Receive EXT_TXD
9 Output Ground DGND
10 Output Ground DGND
11 Output +7Vdc min NCall
12 Output RS-232 or RS-485 TXD
13 Input RS-232 or RS-485 RXD
14 Output 12VDC +/- 5%@ 100mA +12VT
PIN # INPUT/OUTPUT DESCRIPTION NAME
1 Out Chassis Ground CHASSIS
2 Out ground DGND
3 Out +5V supply (+/-5%) VCC
4 Out View angle control -15V max VEE
5 Out TTL, control line WR_LCD*
6 Out TTL, control line RD_LCD*
