Accutorr Plus Service Manual 0070-10-0691 3 - 15
Repair Information Interconnect Cables Run List
3.7 Interconnect Cables Run List
3.7.1 Interface Specifications, Connectors and Functions.
3.7.1.1 Connector to LED / Tone PCB, J-2
PIN # INPUT/OUTPUT DESCRIPTION NAME
1 Vcc return D(digital ground)
2 Output Reset RST_CONN*
3 Input/Output Damped Data Bus D(0) D_DAMP_CONN(0)
4 Input Write Recorder WR_RECD*
5 Vcc return D(digital ground)
6 FPGA Not Done FPGA_NOT DONE*
7 Input/Output Damped Data Bus D(1) D_DAMP_CONN(1)
8 Output Read/ Write R/W_CONN*
9 Vcc return D(digital ground)
10 Output LDS LDS*
11 Input/Output Damped Data Bus D(2) D_DAMP_CONN(2)
12 Output Chip Select I/O CS_IO*
13 Vcc return D(digital ground)
14 Input Write Delay WR_DLY*
15 Input/Output Damped Data Bus D(3) D_DAMP_CONN(3)
16 Input ST Watchdog ST_WDOG*
17 Vcc return D(digital ground)
18 Input LCD Angle LCD_ANGLE
19 Input/Output Damped Data Bus D(4) D_DAMP_CONN(4)
20 Input LCD Angle Feed Back LCD_ANGLE_FB
21 Vcc return D(digital ground)
22 Input LCD Angle Reference LCD_REF
23 Input/Output Damped Data Bus D(5) D_DAMP_CONN(5)
24 Output TONE TONE
25 Vcc return D(digital ground)
26 N/C N/C N/C
27 Input/Output Damped Data Bus D(6) D_DAMP_CONN(6)
28 Input Read Configure RE_CONFG*
29 Vcc return D(digital ground)
30 N/C N/C N/C
31 Input/Output Damped Data Bus D(7) D_DAMP_CONN(7)
32 +5V Supply VCC
33 Vcc return D(digital ground)
34 +5V Supply VCC
