Interconnect Cables Run List Repair Information
3 - 16 0070-10-0691 Accutorr Plus Service Manual
35 Input/Output Damped Data Bus D(8) D_DAMP_CONN(8)
36 N/C N/C N/C
37 Vcc return D(digital ground)
38 +5V Supply VCC
39 Output Clock O CLKO_CONN
40 +5V Supply VCC
41 Vcc return D(digital ground)
42 Input Keypad Data Bus (D0) KEYD0
43 Output Damped Address(2) A_DAMP_CONN(2)
44 N/C N/C N/C
45 Vcc return D(digital ground)
46 N/C N/C N/C
47 Output Damped Address(3) A_DAMP_CONN(3)
48 Input Keypad Data Bus (D3) KEYD3
49 Vcc return D(digital ground)
50 N/C N/C N/C
51 Output Damped Address(4) A_DAMP_CONN(4)
52 N/C N/C N/C
53 Vcc return D(digital ground)
54 N/C N/C N/C
55 Output Damped Address(5) A_DAMP_CONN(5)
56 N/C N/C N/C
57 Vcc return D(digital ground)
58 Output AC ON ACON*
59 Output Damped Address(6) A_DAMP_CONN(6)
60 Input Switched ON/OFF ON/OFFSW*
61 Vcc return D(digital ground)
62 N/C N/C N/C
63 Output Damped Address(7) A_DAMP_CONN(7)
64 N/C N/C N/C
65 Output Vcc return D(digital ground)
66 N/C N/C N/C
67 N/C N/C N/C
68 Output AC LED ON ACON_LED
69 +5V Supply VCC
70 Input High Low HIGH/LOW*
71 +5V Supply VCC
72 Input LCD Unit LCD_UNIT*
73 N/C N/C N/C
74 N/C N/C N/C
PIN # INPUT/OUTPUT DESCRIPTION NAME
