Introduction Calibration
5 - 2 0070-10-0691 Accutorr Plus Service Manual
5.1 Introduction
The Accutorr Plus is a state of the art device employing digital determination and
verification systems to obtain superior performance for the life of the product. Most
function calibration constants are written into the operating software, therefore, for the
most part, there are no means to calibrate or adjust system functions. The instrument
contains extensive Service Diagnostics that will, in most cases, isolate a malfunction to
the lowest serviceable module.
NOTE: This procedure refers to this instrument as the
UUT (Unit Under Test).
All internal verifications and adjustments should be performed with the internal battery
disconnected. Operate the UUT on the main power supply. This will insure a reliable
power source for the test, as well as providing a measure of safety in case of accidental
overload of the power source. To re-initialize the low battery detector circuits, reconnect
the battery at the conclusion of all tests while the UUT is on A.C. power source. Reset the
real-time clock and date, if required.
5.1.1 Status and Error Code Table
The Accutorr Plus uses the various displays on the front panel to display the operational
status. Error codes listed below can generally be resolved by the user however, error codes
with an asterisk (*) may require resolution by a qualified technical service person.
5.1.1.1 Error Codes
Table 5-1
TYPE CODE DESCRIPTION REASON
NIBP 8810 Retry - Unable to
Measure
Motion artifact, cycle time-out, weak pulsations or
no pulsations. A triple beep tone is generated.
8811 Retry - Pump
Higher
Insufficient cuff pressure. A triple beep tone is
generated.
8812 Stop - Cuff
Overpressure
Excessive cuff pressure detected by the software.
A triple beep tone is generated.
8813 Stop - Unable to
Measure
4 successive measurement attempts failed. A triple
beep tone is generated.
TEMP
(PTM)
8830 Check Probe Tissue contact may have been lost.
8831 Replace Probe Defective probe or connection.
