Telemetry PCB using flying leads) or PL13B, PL14B, and PL15B (Issue C
Telemetry PCB using on board connectors).
The Subsea Microcontroller board simply plugs onto the Connector PCB using
plugs PL9, PL10, PL11, and PL12.
Specification
Supply Input:
Controller / Cone +12VDC & +/
-
15VDC
Telemetry +/
-
15VDC
Electrical Installation
A wiring schematic diagram of the Electronics pod is shown in Figure 19.
