Upgrade Procedure
Step 6:
Remove
Removable
Media Drives
1. Loosen the captive screws on either side of the drive bracket.
2. Slide the drive out of the bracket and through the opening in
the front panel.
3. Set the drive aside on an antistatic mat.
Step 7:
Remove Fixed
Disk Drives
1. Press down on the disk drive and unlock the sliding latch.
2. Lift the drive off the mounting post and out of the chassis
cutouts.
MLO-010667
3. Unplug the power cable and SCSI cable from the drive. Pull
on the SCSI cable connector flap to remove the connector.
4. Set the drives aside on an antistatic mat.
5. Put all the disconnected ends of the cables back into the
system unit.
6. Remove all drive mounting brackets by removing the four
screws that secure the drive to the mounting bracket.
Upgrading a DECsystem 5000 Model 133/150 2–5
