DeDietrich AWHP MIT-IN iSystem Installation And Service Manual

outside unit Speed of the
heat pump
heating pump
Nominal
water flow
Minimum flow rate
recommended
l/min l/min
AWHP 14MR/
TR
3 34 25
AWHP 16MR/
TR
4 38 28
AWHP 22TR 5 41 35
AWHP 27TR 5 41 35
1. Close the valve on the exchanger.
2. Unscrew the cover.
3. Dismantle the spring retaining ring.
4. Dismantle the filter.
5. Check and clean the filter.
Replace the filter if necessary.
6. Remount the filter.
7. Tighten the connection.
8. Open the valve on the exchanger.
7.4 Customising maintenance
7.4.1. Maintenance message
The heating generator includes a function used to display a
maintenance message. To set the parameters for this function,
proceed as follows:
1. Access the "After Sales" level: Hold down the
-
key until
#PARAMETERS is displayed.
2. Select the menu #REVISION.
4
Turn the rotary button to scroll through the menus or
modify a value.
4 Press the rotary button to access the selected menu
or confirm a value modification.
¼
For a detailed explanation of menu browsing, refer
to the chapter: "Browsing in the menus", page 75
3. Set the following parameters:
M002646-A
1
2
M002647-A
3
4
bar
1
1
2
2
r
c
STD
(
'
t
v
0 2 4 6 8 10 12 14 16 18 22 2420
p
b
AUTO
x
c
r
j
M
g
m
SUNDAY 11:45
10
"
TEMP.: _ _ _ _
C002272-C-04
7. Checking and maintenance
AWHP MIT-IN iSystem
105
24/09/2012 - 300027606-001-01
