User level - Menu #MEASURES
Parameter Description Unit
TEMP.TANK AUX
(1)
Water temperature in the second DHW tank connected to the AUX circuit °C
DHW A TEMP.
(1)
Water temperature in the second DHW tank connected to circuit A °C
TEMP.SOL.TANK
(1)
Temperature of the hot water produced by solar power (TS) °C
SOLAR.COLL.T.
(1)
Solar panel temperature (TC) °C
SOLA.ENERGY
(1)
Solar energy accumulated in the tank kWh
FLOWMETER
Plate exchanger flow rate l/min
NB IMPULS.COMP
Number of heat pump start-ups
RUNTIME HP
Number of hours' operation of the heat pump compressor h
IN 0-10V
(1)
Voltage at input 0-10 V V
SEQUENCE
Control system sequence
CTRL Software control number (SCU)
(1) The parameter is only displayed for the options, circuits or sensors actually connected.
5.6 Changing the settings
The heat pump control panel is set for the most common heating
installations. With these settings, practically all heating systems
operate correctly. The user or installer can optimise the parameters
according to own preferences.
¼ For the user settings, refer to the user instructions.
5.6.1. Language selection
1. Access the installer level: Press key
-
for around 5 seconds.
2. Select the menu #LANGUAGE.
4
Turn the rotary button to scroll through the menus or
modify a value.
4 Press the rotary button to access the selected menu
or confirm a value modification.
¼
For a detailed explanation of menu browsing, refer
to the chapter: "Browsing in the menus", page 75
Installer level - Menu #LANGUAGE
Adjustment range Description
FRANCAIS Display in French
DEUTSCH Display in German
ENGLISH Display in English
ITALIANO Display in Italian
ESPANOL Display in Spanish
NEDERLANDS Display in Dutch
POLSKI Display in Polish
PУCCKИЙ Display in Russian
TÜRK Display in Turkish
1
1
2
2
r
c
STD
(
'
t
v
0 2 4 6 8 10 12 14 16 18 22 2420
p
b
AUTO
x
c
r
j
M
g
m
SUNDAY 11:45
5
"
TEMP.: 68°
C002235-F-04
5. Commissioning AWHP MIT-IN iSystem
89
24/09/2012 - 300027606-001-01
