WARNING
Be careful that you do not invert the wires.
1 Connect to terminals S2, S3 and *.
2 Connect to terminals S2, S3 and *. (Outside module)
4.11.8. Description of the terminal block on the
inside module
n
MIT-IN/H
A
Bus for communication with the outside module
M002407-B
L N S1 S2 S3
S2 S3
S2S3
1
2
S2 S3
M002410-B
1
S2 S3
AWHP MIT-IN iSystem 4. Installation
24/09/2012 - 300027606-001-01
46
