CAUTION
The integrated filter must be cleaned after one hour's
operation on commissioning.
¼ "Cleaning the 400 µm filter", page 104.
5.4.7. Setting the flow rate threshold
Setting the flow rate threshold is used to select the threshold below
which the heat pump goes into safety shutdown. The flow rate
threshold must be chosen according to the type of outside module
(See table below).
1. Access the installer level: Press key
-
for around 5 seconds.
2. Select the menu #PRIMARY INSTAL.P:
4 Turn the rotary button to scroll through the menus or
modify a value.
4 Press the rotary button to access the selected menu
or confirm a value modification.
¼
For a detailed explanation of menu browsing, refer
to the chapter: "Browsing in the menus", page 75.
Installer level - Menu #PRIMARY INSTAL.P
(1)
Parameter Adjustment range Description Factory setting Customer setting
MIN.MES.FLOW.
OFF / 5 - 60 Flow rate limit below which a message is
displayed indicating that the flow rate is low.
¼ See chapter: "Messages", page
108.
25 l/mim.
MIN.STOP.FLOW.
OFF / 5 - 60 Flow rate limit below which the heat pump goes
into default.
17 l/mim.
(1) The menu is displayed only if the INSTALLATION parameter is set to EXTENDED
Type of group MIN.MES.FLOW. MIN.STOP.FLOW.
l/min l/min
AWHP 6MR 12 8
AWHP 8MR 16 13
AWHP 11MR/TR 19 13
AWHP 14MR/TR 25 17
AWHP 16MR/TR 28 19
AWHP 22TR 35 30
AWHP 27TR 35 30
1
1
2
2
r
c
STD
(
'
t
v
0 2 4 6 8 10 12 14 16 18 22 2420
p
b
AUTO
x
c
r
j
M
g
m
SUNDAY 11:45
5
"
TEMP.: 68°
C002235-F-04
5. Commissioning AWHP MIT-IN iSystem
87
24/09/2012 - 300027606-001-01
