- Water: +7 °C / +25 °C
- Outside air: +15 °C / +40 °C (At less than 18°C, it is necessary
to use the HK24 insulation kit option)
4 Maximum operating pressure: 3 bar
AWHP
6 MR 8 MR 11 MR 11 TR 14 MR 14 TR 16 MR 16 TR 22 TR 27 TR
Calorific output - A7/
W35
(1)
kW 6.0 8.5 10.9 10.9 13.7 13.7 15.7 15.7 19.4 24.4
COP hot - A7/W35
(1)
4.00 4.10 4.23 4.23 4.03 4.03 3.90 3.90 3.94 3.90
Absorbed electrical
power - A7/W35
(1)
kWe 1.5 2.1 2.6 2.6 3.4 3.4 4.03 4.03 4.9 6.3
Nominal amperage -
A7/W35
(1)
A 6.8 9.2 11.2 6.7 14.8 8.8 17.6 10.1 12.3 15.6
Calorific output - A2/
W35
(2)
kW 4.4 5.9 7.6 7.6 10.3 10.3 10.4 10.4 11.6 14.7
COP hot - A2/W35
(2)
3.12 3.12 3.10 3.10 3.10 3.10 3.10 3.10 3.11 3.10
Absorbed electrical
power - A2/W35
(2)
kWe 1.4 1.9 2.5 2.5 3.3 3.3 3.4 3.4 3.9 4.7
Nominal amperage -
A2/W35
(2)
A 6.1 8.2 10.7 6.2 14.5 8.3 14.6 8.4 9.7 11.8
Cooling output
(3)
kW 5.4 7.9 10.5 10.5 11.7 11.7 11.7 11.7 17.7 22.2
EER
(3)
3.80 3.99 4.68 4.68 4.43 4.43 4.43 4.43 3.8 3.8
Absorbed electrical
power
(3)
kWe 1.4 2.0 2.2 2.2 2.7 2.7 2.7 2.7 4.6 5.8
Sound pressure
(4)
dBA 36 36 40 40 41 41 41 41 45 45
Nominal water flow (ΔT
= 5K)
m
3
/h
1.04 1.47 1.88 1.88 2.34 2.34 2.67 2.67 3.8 4.6
Manometric height
available at nominal
flow rate
mbar 618 493 393 393 282 282 213 213 - -
Nominal air flow rate
m
3
/h
2100 3000 6000 6000 6000 6000 6000 6000 8400 8400
Power voltage of the
outdoor unit
V 230 V~ 230 V~ 230 V~ 400 V3~ 230 V~ 400 V3~ 230 V~ 400 V3~ 400 V3~ 400 V3~
Sound output
(5)
dBA 63.7 65.2 65.4 65.4 66.8 66.8 69.4 69.4 67 67
R410A refrigerant kg 2.5 3.6 5 5 5 5 5 5 7.1 7.7
Refrigeration
connection (Liquid-
Gas)
inch 1/4-1/2 3/8-5/8 3/8-5/8 3/8-5/8 3/8-5/8 3/8-5/8 3/8-5/8 3/8-5/8 3/8-3/4 1/2-3/4
Max pre-loaded length m 30 30 30 30 30 30 30 30 30 30
Weight (empty) -
outside unit
kg 45 75 121 135 116 130 116 130 135 141
(1) Hot mode: Outside air temperature +7 °C, Water temperature at the outlet +35 °C. Performances in line with EN 14511-2.
(2) Hot mode: Outside air temperature +2 °C, Water temperature at the outlet +35 °C. Performances in line with EN 14511-2.
(3) Cooling mode: Outside air temperature +35 °C, Water temperature at the outlet +18 °C. Performances in line with EN 14511-2
(4) 5 m from the appliance, free field.
(5) Test conducted in accordance with the standard NF EN 12102
3.4.3. Sensor characteristics
Outside sensor
Temperature in °C -20 -16 -12 -8 -4 0 4 8 12 16 20 24
Resistance in Ω 2392 2088 1811 1562 1342 1149 984 842 720 616 528 454
3. Technical description AWHP MIT-IN iSystem
15
24/09/2012 - 300027606-001-01
