3.3.2. Skeleton Diagrams
n
MIT-IN/H
1
tank
2
Filter
3
Flowmeter
4
Radiator
5
Plate heat exchanger
6
Boiler
n
MIT-IN/E
1
tank
2
Filter
3
Flowmeter
4
Radiator
5
Plate heat exchanger
M002487-D
MIT-IN H
AWHP
M002488-D
MIT-IN E
AWHP
1
6
4
5
2
3
3. Technical description AWHP MIT-IN iSystem
13
24/09/2012 - 300027606-001-01
