DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
22 Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM
5.1 TYPICAL LCD DISPLAY SCREENS
5.1.1 TYPICAL STATUS DISPLAY
Waiting in auto
Indicates that the module is in Automatic. The unit will respond to
an active remote start.
Starting remote
Indicates that the module is in automatic and that a start sequence
has been initiated, with an active remote start. The module is
attempting to crank the generator.
Cranking attempt 1
Running in auto
Indicates that the module is in Automatic, and that the generator is
running on load. This default screen also indicates the average line
to neutral voltage, highest of the 3 phase currents, generator
frequency, average line to line voltage and total kilowatts.
Generator on load
L-N 230V 240A 50Hz
L-L 400V 133kW
5.1.2 TYPICAL INSTRUMENT DISPLAY
Coolant temperature
The display of coolant temperature in both degrees centigrade and
Fahrenheit.
60 ºC 140 ºF
Oil pressure
The display of engine oil pressure in Bar, Pounds Per Square Inch
and kilo Pascal.
6 Bar 87 PSI
600 kPa
Generator Amps
The display of all three generator line currents.
L1 L2 L3
238 241 241
5.1.3 TYPICAL ALARM DISPLAY
Alarm
The module is warning that the engine oil pressure has fallen
below a pre-set level. The generator is not shut down.
Warning
Low oil pressure
Alarm
The oil pressure has fallen below a second pre-set value and has
shut down the generator.
Shutdown
Low oil pressure
Alarm
The module is warning that the battery volts is below a pre-set
value.
Warning
Low battery Volts
To Next Page
