DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM 5
1 INTRODUCTION
The DSE 5310 autostart module has been designed to allow the user to start and stop the generator, and if
required, transfer the load to the generator either manually (via external push-buttons) or automatically. The user
also has facility to view all the system operating parameters via the LCD display.
The DSE 5310 module monitors the engine, indicating the operational status and fault conditions; automatically
shutting down the engine and giving a true first up fault condition of an engine failure by a COMMON AUDIBLE
ALARM. The exact failure mode is indicated by text messages on the LCD display on the front panel.
The powerful microprocessor contained within the module allows for a range of complex features to be
incorporated as standard:
• Text based LCD display (supporting multiple languages).
• Voltage, Current and Power monitoring.
• Engine parameter monitoring.
• Fully configurable inputs for use as alarms or a range of different functions.
• Extensive range of output functions using built in relay outputs or relay expansion modules available.
Selective operational sequences, timers and alarm trips can be altered by the customer via a PC using the 52/53xx
series configuration software and P810 interface. Additionally, a subset of this information can be adjusted from the
module’s front panel configuration editor.
The module is housed in a robust plastic case for front panel mounting. Connections to the module are via locking
plug and sockets.
2 CLARIFICATION OF NOTATION USED WITHIN THIS PUBLICATION.
NOTE:
Highlights an essential element of a procedure to ensure
correctness.
CAUTION!
Indicates a procedure or practice which, if not strictly observed,
could result in damage or destruction of equipment.
WARNING!
Indicates a procedure or practice, which could result in injury to
personnel or loss of life if not followed correctly.
Compliant with BS EN 60950 Low Voltage Directive
Compliant with BS EN 50081-2 EMC Directive
Compliant with BS EN 50082-2 EMC Directive
Indicates a function only applicable when the controller is
configured for connection to a CAN engine controller
