DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM 43
8.2.6 PLUG “G” 5 WAY
PIN No DESCRIPTION
39 Generator L1 current transformer connection.
40 Generator L2 current transformer connection. If single phase is used do not connect this pin.
41 Generator L3 current transformer connection. If single phase is used do not connect this pin.
42 Generator current transformer common connection and CT earth connection.
43 Not used. Do not connect to this terminal.
WARNING! - Do not disconnect this plug when the generator set is running. Disconnection will open
circuit the secondary of the CT’s and dangerous voltages may then develop. Always ensure the
generating set is at rest before making or breaking connections to the module.
8.2.7 PLUG “H” 4 WAY
PIN
No
DESCRIPTION
44 Oil Pressure sensing input. Connect to resistive type oil pressure sender. Refer to connection
diagram for details.
45 Coolant Temperature sensing input. Connect to resistive type coolant temperature sender. Refer
to connection diagram for details.
46 Fuel Level sensing input. Connect to resistive type fuel level sender. Refer to connection diagram
for details.
47 Sender Common connection. Return feed from sender units - refer to connection diagram for
details.
NOTE:- When the module is configured for CAN operation, terminals 44 & 45 should be left
unconnected. Engine oil pressure and coolant temperature is transmitted to the 53xx controller on the
CAN link.
8.2.8 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE
If you require additional plugs from DSE, please contact our Sales department using the part numbers below.
5310 Terminal Connector Plug description DSE Part number
1-8 A BL08 8way 5.08mm spacing connector plug 007-125
9-19 B BL11 11way 5.08mm spacing connector plug 007-135
20-22 C BL03 3way 3.81mm spacing connector plug 007-409
23-26 D BL04 4way 3.81mm spacing connector plug 007-408
35-38 F BL04 4way 10.16mm spacing connector plug 007-003
39-43 G BL05 5way 5.08mm spacing connector plug 007-329
44-47 H BL04 4way 5.08mm spacing connector plug 007-100
NOTE:- Plug E is not fitted to this module.
