DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM 31
6.2.1 LIST OF ADJUSTABLE PARAMETERS IN ‘MAIN CONFIGURATION EDITOR’
Section Parameter Display shows Values
Input settings
Low Oil Pressure warning
Oil pressure pre-alarm
0-4bar (1.17bar)
Low Oil Pressure shutdown
Oil pressure shutdown
0-4bar (1.03bar)
High Temperature warning
Coolant temp pre-alarm
80-140°C (110°C)
High Temperature shutdown
Coolant temp shutdown
80-140°C (120°C)
Low Coolant Temperature
Low Coolant Temperature
65-136°C (65°C)
Timers
Generator transient delay
Gen transient delay
0 -10s (0s)
Start delay
Start delay
0 -60m (5s)
Return delay
Return delay
0 -60m (30s)
Preheat
Preheat
0 -60m (5s)
Crank attempt
Cranking time
0 -60s (10s)
Crank rest
Crank rest
0-60s (10s)
Safety delay
Safety on delay
0-30s (10s)
Overspeed overshoot
Overspeed overshoot
0-10s (0s)
Warming up
Warm up
0-60m (0s)
Cooling run
Cooling
0-60m (60s)
Fail to stop delay
Fail to stop
0-30s (30s)
Low battery volts delay
Battery low delay
0-10m (1m)
High battery volts delay
Battery high delay
0-10m (1m)
Generator
Generator Under voltage shutdown
Gen low voltage shutdown
50-360V ph-N (184V)
Generator Under voltage prealarm
Gen low voltage pre-alarm
50-360V ph-N (196V)
Generator Over voltage prealarm
Gen high voltage pre-alarm
50-360V ph-N (253V)
Generator Over voltage shutdown
Gen high voltage shutdown
50-360V ph-N (265V)
Generator Under frequency shutdown
Gen low frequency shutdown
0 -75Hz (40Hz)
Generator Under frequency prealarm
Gen low frequency pre-alarm
0 -75Hz (42Hz)
Generator Over frequency prealarm
Gen high frequency pre-alarm
0 -75Hz (55Hz)
Generator Over frequency shutdown
Gen high frequency shutdown
0 -75Hz (57Hz)
Generator delayed overcurrent
Delayed high current
100-200% (100%)
Engine
Underspeed (RPM) shutdown
Underspeed shutdown
0-6000RPM (1270)
Underspeed (RPM) warning
Underspeed pre-alarm
0-6000RPM (1350)
Overspeed (RPM) warning
Overspeed pre-alarm
0-6000RPM (1650)
Overspeed (RPM) shutdown
Overspeed shutdown
0-6000RPM (1710)
Overspeed overshoot %
Overspeed overshoot percent
0-10 (0%)
Low DC Voltage
Battery low warning
0-24V (8V)
High DC Voltage
Battery high warning
0-24V (33V)
Charge Alternator Failure
Charge fail warning
0-24V (6V)
Display
Language
Language
ENGLISH
, OTHER
(see note below)
Application
Engine speed selection
Alternative Frequency
Disable, Enable
Volts selection
Alternative Voltage
Disable, Enable
Wiring topography
AC System
3 phase 4 wire
Single phase, 2 wire
3 phase, 3 wire
2 phase 3 wire (L1 & L2)
2 phase 3 wire (L1 & L3)
Full load current rating
Generator Full Load
5A - 6000A (500A)
Droop
Disable, Enable
Droop %
0% - 5%
LCD Contrast
Contrast
Date/Time
Date and Time
dd mmm yyyy hh:mm
NOTE:- Display language selection via the modules front panel configuration editor is between
English and a PC configurable language. This ‘other’ language is configurable using the 5xxx PC
configuration software in conjunction with the P810 interface.
NOTE:- Droop percent is only applicable to CAN controlled engines when CAN is enabled in the
5300 series controller.
To Next Page
