DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
48 Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM
12 FACTORY DEFAULT CONFIGURATION
In the tables below, the icon
# indicates an item that can be adjusted from the module’s front panel editor.
Absence of the
# icon beside an item means that adjustment of this parameter is only possible using the 5300
series configuration software in conjunction with the P810 interface.
For further details on adjustment from the front panel editor, see the section entitled “Front panel configuration”
elsewhere within this manual.
5300 series configuration software. Configuration for 5310 module.
Filename – 5310a.XCF
Printed on 25/10/05
Module settings Value
Base module 5310 Remote start module
Miscellaneous settings Value
Two lines of text (Configuration
description)
Blank
Alternator fitted Yes
Poles 4
Magnetic pickup fitted No
CAN enabled No
AC System 3 phase, 4 wire
VT Ratio Disabled
Number of start attempts 3
Enable fast loading feature No
Audible alarm prior to starting No
Sleep when in stop mode No
All warnings are latched No
Input settings – Analogue | Oil pressure Value
Low oil pressure input type VDO 10 bar
Trip Return
Low oil pressure pre-alarm
#
1.17 Bar 17.0 PSI 1.24 Bar 18.0 PSI
Low oil pressure shutdown
#
1.03 Bar 14.9 PSI N/A
Input settings – Analogue | Coolant
temp
Value
High coolant temp input type VDO 120 degrees C
Trip Return
High coolant temp pre-alarm
#
115°C 239°F 110°C 230°F
High coolant temp shutdown
#
120°C 248°F N/A
Low coolant temp pre-alarm
#
Disabled Disabled
Input settings – Analogue | Fuel level Value
Fuel level input type Disabled
