DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM 11
4.1 WARNINGS
Warnings are non-critical alarm conditions and do not affect the operation of the generator system, they serve to
draw the operators attention to an undesirable condition.
In the event of an alarm the LCD will jump to the alarms page, and scroll through all active warnings and
shutdowns.
BATTERY CHARGE FAILURE, will be displayed if the module does not detect a voltage from the warning light
terminal on the auxiliary charge alternator.
Alarm
Warning
Charge fail
BATTERY LOW VOLTAGE, will be displayed if the module detects that the plant DC supply has fallen below the
low volts setting level. The Battery Low Voltage alarm is delayed by the Low DC Volts Delay timer.
Alarm
Warning
Low battery volts
BATTERY HIGH VOLTAGE, will be displayed if the module detects that the plant DC supply has risen above the
high volts setting level. The Battery High Voltage alarm is delayed by the High DC Volts Delay timer.
Alarm
Warning
High battery volts
MAINTENANCE ALARM, will be displayed if the maintenance period is exceeded (engine running hours or date
interval whichever is configured).
Alarm
Warning
Maintenance alarm
FAIL TO STOP, will be displayed if the module detects the engine is still running when the ‘Fail to stop timer’
expires.
Alarm
Fail to stop
NOTE:- ‘Fail to Stop’ could indicate a faulty oil pressure sender - If engine is at rest check oil sender
wiring and configuration.
