DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
12 Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM
AUXILIARY INPUTS, auxiliary inputs can be user configured and will display the message as written by the user.
Example
Alarm
Warning
Bearing temp high
LOW FUEL LEVEL will be displayed if the fuel level detected by the fuel level sender falls below the low fuel level
setting.
Alarm
Warning
Low fuel level
CAN ECU ERROR If the module is configured for CAN instruments and receives an “error” message from
the engine control unit, ‘Can ECU error” is shown on the module’s display and a warning alarm is
generated.
Example
Alarm
The display will alternate
between the text display and the
manufacturers error codes
Alarm
Can ECU error
Exhaust high
temperature
Can ECU error
SPNnnnnnnn
FMInnnnnnn
