DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
40 Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM
8.1.7 PLUG “H” 4 WAY
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
44 Oil Pressure Input 0.5mm²
AWG 20
Connect to Oil pressure sender
45 Coolant Temperature
Input
0.5mm²
AWG 20
Connect to Coolant Temperature sender
46 Fuel Level input 0.5mm²
AWG 20
Connect to Fuel Level sender
47 Sender Common Return 0.5mm²
AWG 20
Return feed for senders*.
NOTE*:- If using single terminal senders refer to connection diagram. If using earth return type
senders connect return terminals to pin 47 and also connect pin 47 to earth. This is detailed in the
Appendix section entitled “Sender wiring recommendations” elsewhere in this manual.
NOTE:- When the module is configured for CAN operation, terminals 44 & 45 should be left
unconnected. Engine oil pressure and coolant temperature is transmitted to the 53xx controller on the
CAN link.
8.1.8 PC CONFIGURATION INTERFACE CONNECTOR
8-way connector allows connection to PC via the 810 configuration interface.
Module can then be re-configured utilising the
5xxx series configuration
software.
8.1.9 EXPANSION OUTPUT CONNECTOR
The expansion connector allows connection to the 157 relay expansion module
or to the 548 LED Remote annunciator module.
