DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
10 Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM
4 PROTECTIONS
When an alarm is present, the Audible Alarm will sound and the Common alarm LED if configured will illuminate.
The audible alarm can be silenced by pressing the ‘Mute’ button
The LCD display will jump from the ‘Information page’ to display the Alarm Page
Alarm
Warning
Low oil pressure
The type of alarm. E.g. Shutdown or warning
The nature of alarm, eg Low oil pressure.
The LCD will display multiple alarms E.g. “High Engine Temperature shutdown”, “Emergency Stop” and “Low
Coolant Warning” alarms have been triggered. These will automatically scroll round in the order that they occurred;
Running in auto
If no alarms are present the
LCD will display this default
page.
Generator on load
L-N 230V 240A 50Hz
L-L 400V 133kW
In the event of a warning alarm, the LCD will display the appropriate text. If a shutdown then occurs, the module
will again display the appropriate text.
Example:-
Alarm
Shutdown
High engine temperature
Followed by….
Alarm
Shutdown
Emergency stop
Followed by….
Alarm
Warning
Low coolant level
The unit will scroll through all
active alarms in a continuous
loop.
Alarm
Shutdown
High engine temperature
To Next Page
