5.2.1 INSTRUMENT PAGE CONTENT
• Engine speed
• Oil Pressure
• Coolant temperature
• Fuel level (%)
• Engine Hours Run
• DC Battery Voltage
• Charge alternator volts
• Modem Status (GSM only)
• Generator AC RMS Voltage Line-Neutral
• Generator AC RMS Voltage Line-Line
• AC RMS Line Current
• Generator Output
• Number of starts
If enhanced instrumentation is selected, the following instrumentation will become
available, if supported by the engine manufacturer.
• Engine oil temperature
• Inlet manifold temperature
• Coolant pressure
• Fuel pressure
• Fuel consumption
• Total fuel used
• Turbo pressure
5.2.2 MANUALLY SELECTING AN INSTRUMENT
Default display
Running in auto
Generator on load
L-N 230V 240A 50Hz
L-L 400V 133kW
Pressing the DOWN button the LCD will
then show Engine speed.
Engine speed
1500 RPM
50 Hz
Pressing the DOWN button the LCD will
then show Oil pressure.
Oil pressure
6 Bar 87 PSI
600 Kpa
Pressing the button again will scroll through each individual instrument eventually returning to the original
instrument displayed.
NOTE:-Once selected the instrument will remain on the LCD display until the user selects a different
instrument or after a period of inactivity for the duration of the configurable Page Timer, the module will
revert to the initial display.
