DSE Model 5310 Automatic Mains Failure & Instrumentation System Operators Manual
42 Part No. 057-013 5310 OPERATING MANUAL ISSUE 7.1 18/06/2007 ADM
NOTE: - When the module is configured for CAN operation, terminals 17 & 18 should be left
unconnected. Engine speed is transmitted to the 53xx controller on the CAN link.
8.2.3 PLUG “C” 3 WAY
PIN
No
DESCRIPTION
20
CAN port Common. Do not connect this terminal to earth. Use only screened 120Ω cable approved
specifically for use in CAN applications.
21
CAN port H. Use only screened 120Ω cable approved specifically for use in CAN applications.
22
CAN port L. Use only screened 120Ω cable approved specifically for use in CAN applications.
NOTE:- Screened 120Ω impedance cable specified for use with CANBUS must be used.
DSE stock and supply Belden cable 9841 which is a high quality 120Ω impedance cable suitable for
CANbus use (DSE part number 016-030)
8.2.4 PLUG “D” 4 WAY (OPTIONAL)
PIN
No
DESCRIPTION
23 RS485 port Common
24
RS485 port B. Use only screened 120Ω cable approved specifically for use in RS485 applications.
25
RS485 port A. Use only screened 120Ω cable approved specifically for use in RS485 applications.
26 Not used. Do not connect to this terminal.
NOTE:- Screened 120Ω impedance cable specified for use with RS485 must be used.
DSE stock and supply Belden cable 9841 which is a high quality 120Ω impedance cable suitable for
RS485 use (DSE part number 016-030)
NOTE: - Connector E is not fitted to the 5310 remote start module.
8.2.5 PLUG “F” 4 WAY
PIN
No
DESCRIPTION
35 Generator L1 sensing input. Connect to alternator L1 output.
36 Generator L2 sensing input. Connect to alternator L2 output. If using single phase only do not
connect this terminal.
37 Generator L3 sensing input. Connect to alternator L3 output. If using single phase only do not
connect this terminal.
38 Generator N sensing input. Connect to alternator N output.
