Binary inputs Optocoupler, bi-directional
ON: 8 to 36 V DC
Impedance: 4.7 kΩ
OFF: <2 V DC
Analogue in-
puts
-10 to +10 V DC: Not galvanically separated. Impedance: 100 kΩ
0(4) to 20 mA: Impedance 50 Ω. Not galvanically separated
RPM (MPU): 2 to 70 V AC, 10 to 10000 Hz, max. 50 kΩ
Multi-inputs 0(4) to 20 mA: 0 to 20 mA, +/-1 %. Not galvanically separated
Binary: Max. resistance for ON detection: 100 Ω. Not galvanically separated
Pt100/1000: -40 to 250 °C, +/-1 %. Not galvanically separated. To IEC/EN60751
RMI: 0 to 1700 Ω, +/-2 %. Not galvanically separated
V DC: 0 to 40 V DC, +/-1 %. Not galvanically separated
Relay outputs Electrical rating: 250 V AC/30 V DC, 5 A. (UL/cUL Listed: 250 V AC/24 V DC, 2 A resis-
tive load)
Thermal rating @ 50 °C: 2 A: Continuously. 4 A: t
on
= 5 sec., t
off
= 15 sec.
(Unit status output: 1 A)
Open collector
outputs
Supply: 8 to 36 V DC, max. 10 mA
Analogue out-
puts
0(4) to 20 mA and +/-25 mA. Galvanically separated. Active output (internal supply).
Load max. 500 Ω. (UL/cUL Listed: Max. 20 mA output)
Update rate: Transducer output: 250 ms. Regulator output: 100 ms
Load sharing
lines
-5 to 0 to +5 V DC. Impedance: 23.5 kΩ
Galvanic sepa-
ration
Between AC voltage and other I/Os: 3250 V, 50 Hz, 1 min.
Between AC current and other I/Os: 2200 V, 50 Hz, 1 min.
Between analogue outputs and other I/Os: 550 V, 50 Hz, 1 min.
Between binary input groups and other I/Os: 550 V, 50 Hz, 1 min.
AGC-3 installation instructions 4189340728
UK
Technical information
DEIF A/S Page 63 of 65
