Option H8.2
CAN bus interface for external I/O modules.
Terminal
Function
Description
29
Not used
CAN bus communication for Beckhoff external I/O modules
30
Not used
31
CAN-L
32
Not used
33
CAN-H
34
CAN-L
35
Not used
36
CAN-H
Option H9.2 (Modbus RS-232)
Terminal
Function
Description
29
Modbus RTU/ASCII, RS-232
30
DATA GND
31
32
TxD
33
34
RxD
35
36
ML-2 installation instructions 4189340582
UK
I/O lists
DEIF A/S
Page 15 of 64
14
16
