5.2.10 Relay outputs
Term. Name Function
3 Status relay The status relay on the power supply board is a normally closed relay with
the purpose of processor and power supply supervision
4
5 Alarm horn relay/
configurable
The relay is activated on any alarm that appears. The output can be nor-
mally open (terminal 5-6) or normally closed (terminal 6-7)
6
7
8 Configurable
9
10
11 Configurable
12
13
14 Open GB Generator breaker OFF signal. The output can be selected to be normally
open (NO, terminal 14-15) or normally closed (NC, terminal 15-16)
15
16
17 Close GB Generator breaker ON signal. The output can be selected to be normally
open (NO, terminal 17-18) or normally closed (NC, terminal 18-19)
18
19
20 Configurable Configurable digital output (transistor output type)
21 Configurable Configurable digital output (transistor output type)
65 Configurable GOV/AVR control or configurable
66
67 Configurable GOV/AVR control or configurable
68
69 Configurable GOV/AVR control or configurable
70
71 Configurable GOV/AVR control or configurable
72
ML-2 installation instructions 4189340582
UK
I/O lists
DEIF A/S Page 39 of 64
