Option M14.8
4 × relay outputs.
Term. Function Description
126 Relay 126
250 V AC, 8 A max.
Configurable
127
128 Relay 128
250 V AC, 8 A max.
Configurable
129
130 Relay 130
250 V AC, 8 A max.
Configurable
131
132 Relay 132
250 V AC, 8 A max.
Configurable
133
Option M15.8
4 × analogue 4 to 20 mA inputs.
Term. Function Description
126 Input 127 common Common
127 Analogue input 127+ 4 to 20 mA in
128 Input 129 common Common
129 Analogue input 129+ 4 to 20 mA in
130 Input 131 common Common
131 Analogue input 131+ 4 to 20 mA in
132 Input 133 common Common
133 Analogue input 133+ 4 to 20 mA in
5.1.9 Digital inputs
Term. Name Function
23 Alarm inhibit 1/configurable External input for inhibit of selected alarms
24 Remote alarm acknowledge/configu-
rable
25 Configurable/start sync./control (op-
tion G2)
Option G2: Activates synchronisation. The Deload function
is used to open the breaker
26 Configurable/GB open (option G2) Option G2: Breaker feedback signal. The connection
breaker is in position OFF
27 Configurable/GB closed (option G2) Option G2: Breaker feedback signal. The connection
breaker is in position ON
ML-2 installation instructions 4189340582
UK
I/O lists
DEIF A/S Page 24 of 64
