6.1.15 Electronic speed governor
Multi-line 2
Output for
speed governor
66
67
±20 mA
0
If necessary, the current outputs can be converted to voltage using a resistor across the terminals (250 Ω will
convert the +/-20 mA into +/-5 V DC).
For further information on how to connect the analogue output to the most common speed
governors, please refer to:
Application Notes, Interfacing DEIF equipment to governors and AVRs, document number
4189340670 at www.deif.com.
6.1.16 AVR with analogue outputs
Multi-line 2
Output for
AVR
70
71
±20 mA
0
If necessary, the current outputs can be converted to voltage using a resistor across the terminals (250 Ω will
convert the +/-20 mA into +/-5 V DC).
For further information on how to connect the analogue output to the most common AVRs,
please refer to:
Application Notes, Interfacing DEIF equipment to governors and AVRs, document number
4189340670 at www.deif.com.
