5.2.3 Slot #3, digital I/Os
Terminal Function Technical data Description
37 -5 to 0 to 5 V DC Analogue I/O Active load sharing line
38 Com. Common Common for load sharing lines
39 -5 to 0 to 5 V DC Analogue I/O Reactive load sharing
40 -10 to 0 to 10 V DC Analogue input f/P set point (passive)
41 Com. Common Common for 40/42
42 -10 to 0 to 10 V DC Analogue input U/Q set point (passive)
43 Digital input Optocoupler Deload/configurable
44 Digital input Optocoupler Man. GOV UP/configurable
45 Digital input Optocoupler Man. GOV DOWN/configurable
46 Digital input Optocoupler Man. AVR UP/configurable
47 Digital input Optocoupler Man. AVR DOWN/configurable
48 Digital input Optocoupler Fixed frequency/configurable
49 Digital input Optocoupler P load sharing/configurable
50 Digital input Optocoupler Ext. GOV set point/configurable
51 Digital input Optocoupler Fixed voltage/configurable
52 Digital input Optocoupler Q load sharing/configurable
53 Digital input Optocoupler Ext. AVR set point/configurable
54 Digital input Optocoupler Configurable
55 Digital input Optocoupler Configurable
56 Com. Common Common for terminals 43-55
57 NO Relay 57 6 GOV/AVR control or configurable
58 Com. 250 V AC/8 A
59 NO Relay 59 7 GOV/AVR control or configurable
60 Com. 250 V AC/8 A
61 NO Relay 61 8 GOV/AVR control or configurable
62 Com. 250 V AC/8 A
63 NO Relay 63 9 GOV/AVR control or configurable
64 Com. 250 V AC/8 A
AVR control requires option D1.
ML-2 installation instructions 4189340582
