Option H9.2 (Modbus RS-232)
Terminal
Function
Description
29
Modbus RTU/ASCII, RS-232
30
DATA GND
31
32
TxD
33
34
RxD
35
36
Option M14.2 (4 × relay outputs)
Terminal
Function
Description
29
Relay 29
250 V AC, 8 A
Configurable
30
31
Relay 31
250 V AC, 8 A
Configurable
32
33
Relay 33
250 V AC, 8 A
Configurable
34
35
Relay 35
250 V AC, 8 A
Configurable
36
