5.1.4 Slot #4, GOV/AVR (optional)
GOV control requires option G2.
AVR control requires options G2 and D1.
Option M14.4
GOV/AVR or configurable relay output card.
Term. Function Description
65 Relay 65
250 V AC/8 A
GOV/AVR or configurable
66
67 Relay 67
250 V AC/8 A
GOV/AVR or configurable
68
69 Relay 69
250 V AC/8 A
GOV/AVR or configurable
70
71 Relay 71
250 V AC/8 A
GOV/AVR or configurable
72
Option E1
GOV/AVR or transducer output card.
Term. Function Description
65 Not used
66 +/-20 mA out Speed governor/AVR set point output or transducer
(Analogue output 66)
67 0
68 Not used
69 Not used
70 +/-20 mA out Speed governor/AVR voltage set point output or transducer
(Analogue output 70)
71 0
72 Not used
ML-2 installation instructions 4189340582
UK
I/O lists
DEIF A/S Page 17 of 64
