Deif GPU-3 Hydro Installation Instructions

Term. Function Description
65 ANA + Speed governor/AVR set point output or transducer
(Analogue output 66)
66 ANA -
67 Not used
68 Not used
69 Relay 69
250 V AC, 8 A
GOV/AVR control or configurable
70
71 Relay 71
250 V AC, 8 A
GOV/AVR control or configurable
72
Option EF5
PWM GOV and AVR combination output card.
Term. Function Description
65 +/-25 mA out AVR set point output
66 0
67 PWM + PWM speed governor signal
68 PWM -
69 Relay 69
250 V AC, 8 A
GOV/AVR control or configurable
70
71 Relay 71
250 V AC, 8 A
GOV/AVR control or configurable
72
ML-2 installation instructions 4189340582
UK
I/O lists
DEIF A/S Page 19 of 64
