Deif GPU-3 Hydro Installation Instructions

Option M13.6
7 × digital inputs.
Term. Function Description
90 Common Common
91 Digital input 91 Configurable
92 Digital input 92 Configurable
93 Digital input 93 Configurable
94 Digital input 94 Configurable
95 Digital input 95 Configurable
96 Digital input 96 Configurable
97 Digital input 97 Configurable
Option M14.6
4 × relay outputs.
Term. Function Description
90 Relay 90
250 V AC, 8 A max.
Configurable
91
92 Relay 92
250 V AC, 8 A max.
Configurable
93
94 Relay 94
250 V AC, 8 A max.
Configurable
95
96 Relay 96
250 V AC, 8 A max.
Configurable
97
Option M15.6
4 × analogue 4 to 20 mA inputs.
Term. Function Description
90 Input 90 common Common
91 Analogue input 91+ 4 to 20 mA in
92 Input 92 common Common
93 Analogue input 93+ 4 to 20 mA in
94 Input 94 common Common
95 Analogue input 95+ 4 to 20 mA in
96 Input 96 common Common
97 Analogue input 97+ 4 to 20 mA in
ML-2 installation instructions 4189340582
UK
I/O lists
DEIF A/S Page 21 of 64
