Indicator A Tolerance
XL144 138.5
XL192 186.5
2.3 Mounting XL indicators
Mounting follows the standard DIN mounting for indicators. Use the fixing clamps to mount the indicator from the rear.
Indicators with IP52 protection use two clamps for size 72 and 96 and four clamps for size 144 and 192. If the indicator is
mounted according to IP66, use the gasket and all the clamps supplied, so the pressure on the gasket becomes uniform.
See appendix for more information about indicator outlines.
NOTE
Mount the included (blue) gasket in the groove on the frame with the flat side in the groove and the rounded side
oriented outward. Ensure that the gasket is evenly mounted.
Installation and commissioning guide 4189350024O EN Page 16 of 39
