Delios DLS 300 - Page 25

Fig. 19
FUNCTION SELECTOR:
- Position 1 = LD1
- Position 2 = LD2
- Position 3 = LD3
- Position 4 = LD4
- Position 5 = AUX
- Position 6 = GEN
NC (NORMALLY CLOSE)
MAX 4A - 250V
AC
NO (NORMALLY OPEN)
COMMON
1
1
2
2
6
6
3
3
5
5
4
4
DLS / DLS-C Series
25
Cod.: 240.010.0042
