Delios DLS 300 - HYBRID AC Mode

44
Cod.: 240.010.0042
DLS / DLS-C Series
3.2.7 "HYBRID AC" Mode
This operating mode is mainly indicated to be used in combination with an existing PV plant where there is
a low tariff for the energy fed into the network and a high cost for the energy purchased by the distributor.
In the presence of sunshine, the energy from the existing PV plant and
from the additional PV eld connected to the DLS is used primarily to
supply the domestic loads and secondly to charge the battery. Further
energy in excess is transferred to the grid. If the energy required by the
loads is high and the available energy from the existing PV plant plus
the additional photovoltaic eld and battery is not enough, the missing
part is drawn from the network.
In the absence of energy from the existing PV plant and from the addi-
tional PV eld connected to the DLS, the battery is discharged to sup-
ply domestic loads. If the energy required by the loads is high and the
energy from the battery is not enough, the missing part is drawn from
the network. The energy stored in the battery is never fed into the grid
but is used exclusively to supply the home loads.
