DLS / DLS-C Series
73
Cod.: 240.010.0042
7.5 "INFO" Menu
Access to the “INFO” menu to view general system information:
SISTEM PARAMETERS
FW VERSION
NETWORKING
INFO
Serial Number
Inverter Temp.
Battery Temp.
R iso PV1
R iso PV2
R iso COM
Device FW
DSP A FW
DSP B FW
DSP C FW
Disp FW
LAN
WLAN
IP Address
IP Address
Netmask
Gateway
Netmask
Gateway
Signal [dBm]
SSID
I diff
I diff Test
L-ION Info
1. "SYSTEM PARAMETRS" - The page displays the operating parameters monitored by the system
such as:
Serial Number Unit serial number
Inverter Temp Inverter internal temperature
Battery Temp Battery temperature
R iso PV1 Insulation resistance + PV1 to earth
R iso PV2 Insulation resistance + PV2 to earth
R iso COM Insulation resistance – PV1 and - PV2 to earth
I diff Measured leakage current to earth
I diff Test Measured test leakage current to earth
L-ION info Battery info (if transmitted by battery BMS)
