DLS / DLS-C Series
109
Cod.: 240.010.0042
11 TECHINCAL DATA
11.1 Rating Plate
To locate the rating plate on the equipment, refer to Figure 21.
The technical specications shown in this manual do not replace those appearing on the rating plate at-
tached to the equipment.
The labels attached on the equipment must NEVER be removed, damaged, soiled or hidden for any rea-
son.
The information reported on the rating plate:
1. Manufacturer
2. Model
3. Ratings
4. Certication marks
5. Warnings and usage instructions.
The labels must NOT be hidden with foreign objects (rags, boxes, equipment etc.); they must be periodi-
cally cleaned and kept always clearly visible.
11.2 DLS Technical Datasheet
DLS 300 DLS 450 / DLS 450H DLS 600L / DLS 600
DC inputs
Maximum input power 4.5 kW 6 kW 8 kW
Maximum input voltage 600 V
Minimum input voltage 115 V
Nominal input voltage 400 V
FV MPPT voltage range 100 V - 550 V
Maximum power x MPPT 2.5 kW 3 kW 4 kW
DC voltage range - MPPT @ Pdc max 175 V - 550 V @ 2 kW 230 V - 550 V @ 3 kW 310 V - 550 V @ 4 kW
Maximum input current x MPPT 13A 20A 20A
Short-circuit current x MPPT 15A 25A 25A
Number of MPPTs 2
Maximum number of strings x MPPT 1+1 2+2 2+2
Battery charger
Battery type Litio
Battery voltage range 40 V - 65 V
Max. battery current 66 A 66 A / 100 A 66 A / 100 A
Nominal battery voltage 48 V
Max. charging power 2 kW 2 kW / 3 kW 2 kW / 3 kW
Max. discharging power 3 kW 3 kW / 4.5 kW 3 kW / 4.5 kW
Communication interfaces CAN
