DLS / DLS-C Series
51
Cod.: 240.010.0042
To prevent the risk of electric shock or other injury, check that there are no electrical or hydraulic lines in the
walls before drilling the mounting holes of the DLS. Please note that the appropriate type of plastic plugs
and screws must be selected by qualied installer, based on the following considerations:
• the installation location, as well as
• the type of the wall on which the system is to be mounted to ensure that the mounting of the hybrid
inverter is done as safely as possible
Make sure there is enough free space for air circulation around the DLS. Local regulations may require
larger clearances.
If you mount the DLS in a cabinet, a piece of furniture or in another relatively small and closed space, it is
necessary to ensure enough air circulation to dissipate the heat generated by the unit.
4.5 Mounting the DLS
The DLS is delivered with a wall mounting bracket suitable for use on most walls.
How to mount the DLS:
1. Fix the top and bottom mounting brackets to the DLS body (Follow the instructions shown in Figure 01).
2. Drill the holes to x the DLS mounting support on the wall.
3. Fix the mounting support to the wall
4. Install the DLS.
5. Fix the DLS to the wall using the bottom bracket xing screw.
