Delios DLS 300 - DLS-C Technical Datasheet

112
Cod.: 240.010.0042
DLS / DLS-C Series
11.3 DLS-C Technical Datasheet
DLS 300C DLS 450C DLS 600C
DC inputs
Maximum input power 4.5 kW 6 kW 8 kW
Maximum input voltage 600 V
Minimum input voltage 115 V
Nominal input voltage 400 V
FV MPPT voltage range 100 V - 550 V
Maximum power x MPPT 2.25 kW 3 kW 4 kW
DC voltage range - MPPT @ Pdc max 175 V - 550 V @ 2.25 kW 230 V - 550 V @ 3 kW 310 V - 550 V @ 4 kW
Maximum input current x MPPT 13A 20A 20A
Short-circuit current x MPPT 15A 25A 25A
Number of MPPTs 2
Maximum number of strings x MPPT 1+1
Battery charger
Battery type Litio
Battery voltage range 40 V - 65 V
Max battery current 35 A
Nominal battery voltage 48 V
Max charging power 1,7 kW
Max discharging power 1,7 kW
Communication interfaces CAN
AC output
Grid connection 1P+N+PE
Sn nominal power 3 kVA 4.5 kVA 6 kVA
P maximum active power 3 kW 4.5 kW 6 kW
AC voltage range 230 Vac ± 15% (*)
Output nominal current 13 A 19.6 A 26.1 A
Grid nominal frequency 50 Hz
Frequency range 47 Hz - 53 Hz (*)
Cos ϕ 1 (adj ± 0.80)
THD < 3 %
EPS output
Maximum Smax power (PV+BATT) 3 kVA 4.5 kVA 6 kVA
Maximum Smax power (BATT) 1.7 kVA
AC voltage range 230 Vac ± 15% (*)
Output nominal current 13 A 19.6 A 26.1 A
Grid nominal frequency 50 Hz
Intervention time < 5 sec (*)
THD < 3%
Operating performance
Maximum Effciency 97 %
Weighted effciency (Euro) 96 %
Battery typical effciency 94 %
