DLS / DLS-C Series
65
Cod.: 240.010.0042
7. "GRID" icon: The "GRID" icon shows if energy is being drawn from the national grid. The ow and the
direction of energy coming from that source is displayed on the bar located next to the icon. The num-bers
shown above the bar, which can be scrolled by simply pressing the bar itself, display in real time the volta-
ge, current and power parameters of to the national grid.
8. "HOME" icon: The "HOME" icon shows if there are loads which draw power from the system. The ow of
energy drawn by the residential system is displayed on the bar located next to the icon. The number shown
above the bar displays in real time the power drawn by the system.
9. "GENERAL ALARM" icon: If the "GENERAL ALARM" icon is on, the system has detected a fault. The
code of the alarm detected by the system is displayed on the system status bar (see the "Troubleshooting"
section). By touching the icon, the list of alarms recorded by the system will be displayed.
10. "USB/Wi-Fi" icon: Activation of the "USB" icon indicates that an external USB memory is connected to
the port on the control panel. Similarly, the activation of the "Wi-Fi" icon indicates that a Wi-Fi dongle has
been connected (transparent icon) and that a connection to a local Wi-Fi network has been estab-lished
(icon highlighted)
WARNING: The display cannot be considered a measuring instrument. The measurements shown
on the display are indicative and therefore are not suitable for calculating the efciency or produc-
tion yield.
