About this task
The following images indicate the location of the side cover and provide a visual representation of the installation procedure.
Steps
1. Align the tabs on the side cover with the slots on the chassis.
2. Press the side cover back towards the side of the computer to secure it.
NOTE: The release latch automatically locks the side cover to the computer.
3. Insert the side-cover key into the key slot and turn it clockwise to lock the side cover.
16
Removing and installing components
