Dell D03T Service Manual

Steps
1. Loosen the thumb screw on the front I/O bracket and unscrew it until the front I/O bracket is free to move.
2. Move the top end of the front I/O bracket at an angle to free it from its slot on the chassis.
3. Remove the front I/O bracket from the computer.
Installing the front I/O bracket
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the front I/O bracket and provide a visual representation of the installation
procedure.
Steps
1. Position the front I/O bracket to align the tabs on the bracket with the slots on the chassis.
2. Push in and tighten the thumb screw to secure the front I/O bracket to the chassis.
Next steps
1. Install the front bezel.
2. Install the side cover.
3. Follow the procedure in After working inside your computer.
Removing and installing components
19
