Steps
1. Remove the fan cable from the routing guide on the fan assembly.
2. Locate the position of rubber grommets.
3. Gently pull the rubber grommets inwards to release the fan from the fan cage.
4. Remove the fan from the fan cage.
NOTE: Follow the same steps for the second fan.
Installing the rear fan
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the rear fan and provide a visual representation of the installation procedure.
56
Removing and installing components
