Dell EMC Edge Gateway 5200 User Manual

Dell EMC Edge Gateway 5200
78 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #12 background imageLoading...
Page #12 background image
240 mm
Figure 3. EGW-5200 side view (including wall-mount brackets)
211 mm
238 mm
86 mm
88 mm
Figure 4. EGW-5200 front view (including wall-mount brackets)
136 ± 2
110.9 ± 2
6.0
Figure 5. WiFi antenna (dimensions in mm)
12
Specifications
