Conducted Rx sensitivity and Tx power
NOTE: Values in the following tables are preliminary, pending transceiver matching/testing.
Table 47. Conducted Rx (receive) sensitivity - LTE bands
LTE bands Conducted Rx sensitivity (dBm)
Primary (Typ) Secondary (Typ) SIMO (Typ) SIMO
a
(Worst
case)
B1 Full RB on
downlink; BW: 10
MHz
b
–97.5 –97.5 –100.0 –96.3
B2 –98.0 –97.5 –100.5 –94.3
B3 –97.0 –98.0 –100.5 –93.3
B4 –97.0 –98.0 –100.0 –96.3
B5 –99.0 –100.5 –102.5 –94.3
B7 –97.0 –99.0 –101.0 –94.3
B8 –98.5 –100.5 –102.5 –93.3
B9 –97.0 –98.5 –100.5 –95.3
B12 –98.0 –101.0 –102.5 –93.3
B13 –98.0 –101.0 –103.0 –93.3
B18 –99.0 –101.0 –103.0 –96.3
B19 –98.5 –100.5 –102.5 –96.3
B20 –98.5 –101.0 –103.5 –93.3
B26 –99.0 –100.5 –102.5 –93.8
B28 –98.5 –100.5 –102.5 –94.8
B29 –97.0 –101.0 –102.5 –93.3
B30 –97.0 –99.0 –101.0 –95.3
B32 –99.5 –98.0 –101.5 –96.3
B41 –96.5 –98.0 –100.5 –94.3
B42
c
–97.0 –98.5 –101.0 –95.0
B43
c
–97.0 –97.5 –101.0 –95.0
B48
c
–97.0 –98.0 –101.0 –95.3
B66 –97.0 –98.0 –100.0 –95.8
B46 Full RB on
downlink; BW: 20
MHz
–96.5 –97.0 –99.0 –88.5
a.
Per 3GPP specification.
b.
Sensitivity values scale with bandwidth: x_MHz_Sensitivity = 10_MHz_Sensitivity – 10*log(10 MHz/x_MHz)
c.
B42/B43/B48 disabled as of publication date, support pending regulatory approval.
Table 48. Conducted Rx (receive) sensitivity - UMTS bands
UMTS bands Conducted Rx sensitivity (dBm)
Primary (Typ) Secondary (Typ) Primary/secondary
(Worst case)
a
B1 0.1% BER 12.2 kbps –110.6 –110.5 –106.7
70 Wireless Specifications
