Dell EMC Edge Gateway 5200 User Manual

Table 50. 5G features (continued)
Feature Implementation
Category 3GPP Rel 15
Output power FR1 (Sub 6G): n41, n77, n78, n79: 26 dBm +2/–3 dB all other bands: 23 dBm ±2 dB
4G
Bands FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30,
B32, B66, B71 TDD: B34, B38, B39, B41, B42, B48 LAA: B46 (DL only)
Band combinations For supported carrier aggregations (CA)
4x4 MIMO B1, B2, B3, B4, B7, B25, B30, B66, B38, B41, B42, B48
RX diversity all LTE bands
Category UE Cat. 13 (UL: 150 Mbps) + UE Cat. 20 (DL: 2 Gbps); 7xDL CA, 3xUL CA (Intra-band), 5xDL
CA+4X4 MIMO (Up to UE Cat20)
Output power B41: 26 dBm +2/–3 dB all other bands: 23 dBm ±2 dB
3G
Bands Bd.I, Bd.II, Bd.IV, Bd.V (Bd.VI, Bd.XIX), Bd.VIII, Bd.IX
RX diversity all 3G bands
Category DC-HSPA+ - DL Cat. 24 (42 Mbps) / UL Cat. 6 (11 Mbps) HSUPA - UL 5.76 Mbps
Compressed mode (CM) supported according to 3GPP TS25.212
Output power all bands: 24 dBm +1.7/–3.7 dB
Antenna interface specification
Measurement conditions: ambient temperature = 25°C, V
3V3
= 3.3 V
Typical values, RX measured at 10 MHz bandwidth, TX 1 RB at max
Table 51. RF antenna interface LTE/5G NR
Conditions Tx PRx DRx PRX MIMO DRX MIMO Unit
LTE 2100 Band 1 23.3 –97 –97.5 –97.5 –97.5 dBm
LTE 1900 Band 2 23.2 –97 –97 –97 –97.5 dBm
LTE 1800 Band 3 23.9 –97 –97 –97 –97.5 dBm
LTE AWS-1 Band 4 23.5 –97 –98 –97.5 –97 dBm
LTE 850 Band 5 23.2 –99.5 –101
a a
dBm
LTE 2600 Band 7 23.4 –97 –97.5 –97 –96.6 dBm
LTE 900 Band 8 23.7 –99.5 –100.5
a a
dBm
LTE 700 Band 12 23.5 –99.5 –100.5
a a
dBm
LTE 700 Band 13 23.1 –100 –100
a a
dBm
LTE 700 Band 14 23.4 –99.5 –100
a a
dBm
LTE 700 Band 17 23.2 –100 –100
a a
dBm
LTE 800 Band 18 23.9 –99.5 –100.5
a a
dBm
LTE 800 Band 19 23.3 –99.5 –101
a a
dBm
LTE 800 Band 20 23.9 –99.5 –100.5
a a
dBm
LTE 1900 Band 25 23.7 –97 –96.5 –97.5 –97 dBm
72 Wireless Specifications
