Specifications
Topics:
• EGW-5200 system specifications
•
EGW-5200 system block diagram
• Matrix of expansion modules
• Display options
• Mechanical dimensions
EGW-5200 system specifications
Table 1. EGW-5200 system specifications
EGW-5200
CPU and chipset
Processor Intel
®
Core™ i7-9700TE (8-cores,
35 W, 1.8/3.8 GHz)
Intel
®
Core™ i5-9500TE (6-cores,
35 W, 2.2/3.6 GHz)
Intel
®
Core™ i3-9100TE (4-cores,
35 W, 2.2/3.2 GHz)
Chipset C246
Memory 2x DDR4 SO-DIMM socket, supporting up to 32 GB DDR4 per socket, for a total of 64 GB
I/O interface
Display 2x DP++, DVI-D, VGA (three independent displays)
Ethernet 3x Intel GbE (2x i210 + i219LM PHY, iAMT supported on i5 and i7 CPUs)
Serial ports COM1/2: RS-232/422/485, COM3/4: RS-232
DI/O 8-ch DI and 8-ch DO
USB 6x external USB ports (2x USB 3.1 Gen 2, 1x USB 3.1 Gen 1, 3x USB 2.0), one internal USB 2.0 port
Audio Line-out, mic-in
Mini PCIe 1x full size (USB 2.0 + PCIe), used for WiFi by default
M.2 1x socket 2, key B+M or B, 1x 2280/3042 (USB 3.1 + SATA 6 Gb/s + 2x PCIe)
USIM 2
Security
TPM TPM 2.0
Storage
2.5" SATA 2x internal
Physical
Dimensions 211 mm (W) x 240 mm (D) x 86 mm (H) or 8.27" x 9.45" x 3.39"
Weight 4.7 kg (10.36 lbs)
Mounting Desktop, operational: wall mount
Power supply
DC input 12–24 VDC (±10% tolerance)
2
Specifications 7
