Table 48. Conducted Rx (receive) sensitivity - UMTS bands (continued)
UMTS bands Conducted Rx sensitivity (dBm)
Primary (Typ) Secondary (Typ) Primary/secondary
(Worst case)
a
B2 –111.2 –110.4 –104.7
B4 –110.1 –110.6 –106.7
B5 –111.4 –113.5 –104.7
B6 –111.2 –113.5 –106.7
B8 –111.4 –113.4 –103.7
B9 –110.1 –111.3 –105.7
B19 –111.1 –113.4 –106.7
a.
Per 3GPP specification.
Table 49. Conducted Tx (transmit) power tolerances
Bands Conducted Tx power Notes
LTE
LTE bands 1,2,3,4,5,8,9,12,13,18,19,20,26,28,66 +23 dBm ± 1 dB -
LTE bands 7,41,42
a
,43
a
,48
a
+22 dBm ± 1 dB -
UMTS
Band 1 (IMT 2100 12.2 kbps) +23 dBm ± 1 dB Connectorized (Class 3)
Band 2 (UMTS 1900 12.2 kbps)
Band 4 (AWS 1700/2100 12.2 kbps)
Band 5 (UMTS 850 12.2 kbps) Band 6 (UMTS 800 12.2 kbps)
Band 8 (UMTS 900 12.2 kbps)
Band 9 (UMTS 1700 12.2 kbps)
Band 19 (UMTS 800 12.2 kbps)
a.
B42/B43/B48 disabled as of publication date, support pending regulatory approval.
5G features
Table 50. 5G features
Feature Implementation
General
Data throughput DL 3.88 Gbps (max. theoretical: 4.14 Gbps) at EN-DC: DC_3C-1A-7C-n78A with LTE 5CA 4x4
MIMO (20 Layers) + Sub6G 4x4 MIMO UL 632 Mbps (max theoretical: 660 Mbps) at (EN-DC:
DC_7C-n78A with LTE UL CA + Sub6G SISO)
5G
Bands FR1 (Sub 6G): FDD: n1, n2, n3, n5, n7, n8, n12, n20, n28, n66, n71 TDD: n38, n41, n77, n78, n79
Band combinations For supported E-UTRAN New Radio Dual Connectivity (EN-DC)
4x4 MIMO n1, n2, n3, n7, n66, n38, n41, n77, n78, n79
DSS n1, n3, n5, n28, n66, n71
Wireless Specifications 71
