Power consumption
Power consumption as follows is based on lab data in which 24 V DC is applied and current is measured by the DC power supply.
The power consumption (W) is calculated as the product of applied voltage (V) and the current (A).
Platforms tested for this data have available external I/O interfaces, and are attached to supported devices such as VGA and
DVI monitors, PS2 keyboard/mouse, USB dummy load, COM loopback, and audio loopback, and an internal hard disk driver is
installed.
Information is presented for reference only. Actual power consumption will vary with different attached devices and operating
system.
Table 22. Power consumption
System Power off System idle Processor full
load
System full load Recommended
power supply
EGW-5200 Intel Core i7 3.6 W 24 W 65 W 97 W >120 W
EGW-5200 Intel Core i5 3.7 W 22 W 64 W 94 W >120 W
EGW-5200 Intel Core i3 3.8 W 22 W 56 W 85 W >120 W
NOTE: Sufficient power supply for the entire system is required to meet these specifications. At least 120 W at 24 V input
is recommended
NOTE: Heat generated by add-on PCI/PCIe adapters affects thermal stability. Additional heat dissipation is required when
the system operates at high temperatures or in harsh environments with add-on adapters.
A
Power consumption 29
